Uri sa Boltahe: DC
Type sa Motor: BLDC External Rotor Motor
Diametro sa Impeller: 140mm
Materyal nga Impeller: Galvanized Steel
Pagkontrol sa Speed: 0-10VDC/PWM
Type sa Proteksyon: IP44
Klase sa Insulasyon: B
Temperatura sa Operasyon: - 25 ℃ ~ + 60 ℃
Proteksyon sa Motor: Locked-Rotor Protection, Reverse Polarity Protection, Thermal Protection, Soft Start
| Model No. | Sistema sa Pagdala | rated boltahe | operating boltahe | Rated nga Current | rated Gahum | Na-rate nga Speed | Air Flow | Air Pressure | Ang lebel sa lanog |
| B / S | VDC | VDC | A | W | RPM | m³ / h | Pa | DBA | |
| F3D-24140-S9-00 | Ball | 24 | 16 ~ 28 | 6.25 | 150 | 2560 | 590 | 554 | 70 |
| F3D-48140-S9-00 | Ball | 48 | 36 ~ 57 | 3.1 | 150 | 2560 | 590 | 554 | 70 |
